Alpha 65 Evo

Active 2-way studio monitor

With its tweeter and its Woofer 16.5 cm with Slatefiber membrane, two speakers signed focal, Alpha 65 Evo is a monitoring enclosure with dynamics, the neutrality of tonal balance and excellent sound consistency, whatever the Listening place. Its compactness and great versatility make it discreet and efficient equipment for all professionals.

• Product type : 2-way monitor

• Loudspeakers :
  • Woofer : 6,5" Slatefiber membrane
  • Tweeter : 1" Aluminium inverted dome

• Frequency response (+/- 3dB) :
  40 Hz - 22 kHz

• Maximum SPL (peak@1m) :
  104 dB

• Inputs :
  • TRS: symmetrical 10 kOhms
  • XLR: symmetrical 10 kOhms
  • RCA: asymmetrical 10 kOhms with compensanted sensitivity

• LED :
  Power On LED

• Local supply :
  100 - 240V - (T2AL fuse/250V)

• High frequency amplifier :
  30 W, class D

• Bass level (>250Hz) : Adjustable +/-6dB

• Power on/of : On/Off switch on the rear panel

• Mid-range and low frequency amplifier :
  55 W, class D

• Treble level (< 4.5kHz) : Adjustable +/-3dB

• Indicators and controls :
  • Sensitivity
  • Auto standby
  • LF Shelv, HF Shelv

• Height : 33.9 cm / 13.35 in

• Width : 26.1 cm / 10.28 in

• Depth : 28.9 cm / 11.38 in

• Weight : 7.6 kg / 16.8 livre

Headphones

• Closed

• Circumaural

• Conversion technology for acoustic transparency and dynamics

• Impedance: 32 Ohms

• Sensitivity (@ 1 kHz - / 1 Vrms): 122 dB SPL

• THD (THD, @ 1 kHz / 100 dB SPL): 0.3%

• Frequency range: 5 Hz to 22 kHz

• Connection: 3.5 mm jack with 4 contacts

• Dimensions: 239 x 212 x 111 mm

• Weight: 280 g

• Includes spiral cable (5 m) and straight cable (1.4 m)

Active 2-Way Bass Reflex Studio Monitor

• Equipped with: 6.5" TMD woofer (Tuned Mass Damper) and 1.5’ beryllium tweeter

• Switchable focus mode: 1-way full-range monitor (woofer only)

• Frequency range (-3dB) : 45 Hz - 40,000 Hz in 2-way mode and 110Hz - 10,000 Hz in 1-way mode

• Maximum SPL: 50-10,000 Hz, free field @ 1m / 110 dB

• Amplifier power (RMS): 80 W (woofer) + 50 W (tweeter)

• Adjustable high-pass filter

• Low- und High-Shelving-EQ und Low-Mid-EQ: 160 Hz

• Switchable stand-by function

• Adjustable input sensitivity: +4 dBu / -10 dBV

• XLR Input

• Focus input and output: 6.3 mm jack

• MDF housing with veneered side panels in black

• Dimensions (H x W x D): 334 x 24.6 x 29.5 mm

• Weight: 13 kg

Active Studio monitor

• Tweeter: 1" Inverted aluminium dome (30W Class D)

• 2x Bass/midrange drivers: 6.5" carbon fibre cone (2x 50W Class D)

• Frequency range: 38Hz - 22,000Hz (+/- 3dB)

• Max. SPL: 108dB (peak @ 1m)

• Inputs: 1x jack (6.3mm, balanced), 1x XLR (balanced) and 1x RCA (unbalanced)

• Input impedance: 10 kOhm

• Low shelf filter: +/- 6dB (0 - 250Hz)

• High shelf filter: +/- 3dB (4.5 - 35kHz)

• Auto standby after approx. 15 minutes without operation

• Dimensions (H x W x D): 260 x 550 x 290 mm

• Weight: 12.2 kg

• Includes cover grille

Shape 40

Monitoring speaker

Shape 40 is the ideal answer for close monitoring. Thanks to exclusive Focal innovations, this professional work tool offers a wide frequency range in the bass and precise control, right down to the extreme treble. Whether it's a room smaller than 10 m², or an installation where compactness is paramount, Shape 40 is the solution.

• Product type : 2-way monitor

• Loudspeakers :
  • Woofer : 4" Flax membrane
  • Tweeter : 1" Aluminium-Magnisium M shaped dome

• Frequency response (+/- 3dB) :
  60 Hz - 35 kHz

• Maximum SPL (peak@1m) :
  102 dB

• Bass/midrange level (160 Hz) : Adjustable, +/-3 dB

• Inputs :
  • XLR: symmetrical 10 kOhms
  • RCA: asymmetrical 10 kOhms with compensanted sensitivity

• High-pass filter :
  Full range, 80 Hz

• LED :
  Power On LED

• Local supply :
  220-240V (T500mAL / 250V fuse) or 100-120V (T1.6AL / 250V fuse)

• High frequency amplifier :
  25 W, class AB

• Bass level (>250Hz) : Adjustable +/-6dB

• Power on/of : On/Off switch on the rear panel

• Mid-range and low frequency amplifier :
  25 W, class AB

• Treble level (< 4.5kHz) : Adjustable +/-3dB

• Indicators and controls :
  • HPF, LF Shelv, LMF EQ, HF Shelv

• Height : 25.7 cm / 10.1 in

• Width : 16.1 cm / 6.3 in

• Depth : 20 cm / 7.9 in

• Weight : 5 kg / 16.1 livre

Active studio monitor

• Tweeter: 1" inverted aluminium dome tweeter, 20 W (class D)

• Woofer: 5" carbon fibre cone, 30 W (class D)

• Frequency range: 45 Hz - 22 kHz (+/- 3 dB)

• Max. SPL: 101 dB (peak at 1 m)

• Inputs: 1 x 6.3 mm (1/4") jack (balanced), 1 x XLR (balanced), and 1 x RCA (unbalanced)

• Input impedance: 10 kOhm

• Low-shelf filter: +/- 6 dB (0 - 300 Hz)

• High-shelf filter: +/- 3 dB (4.5 Hz - 22 kHz)

• Auto-standby after approx. 15 minutes without operation

• Dimensions (H x W x D): 310 x 228 x 239 mm

• Weight: 6 kg

Nearfield Active Monitors

Focal Shape 50

• Bi-amplified nearfield studio monitor

• 5" Flax sandwich cone woofer

• 1" tipped tweeter

• Low tweeter directivity for flexible listening position

• Flexible settings for listening position

The Focal Shape 50 (Single) studio monitor is a compact 5" nearfield studio monitor featuring a unique Flax sandwich cone and a 5" passive radiator. The Focal Shape 50 is a highly innovative nearfield studio monitor, incorporating a wide range of revolutionary technology and premium-level components. The Shape 50 Studio Monitor offers low tweeter directivity for flexible listening placement, designed without a baffle so you can place it next to a wall. The monitor can be used from 80 cm for greater flexibility. The extended frequency range (50Hz - 35kHz) ensures capture of all nuances of your source audio, ideal for mixing and mastering applications.

Full Description

Innovative Nearfield Monitoring

The Focal Shape 50 Studio Monitor is a compact nearfield studio monitor with a unique design including a dual 5" passive radiator. The 1" M-shaped inverted aluminum/magnesium dome tweeter pairs with the 5" Flax sandwich cone woofer to deliver extended low-frequency reach. The Focal Shape 50 is designed without a baffle so it can be placed close to a wall. These monitors can also be used from 60 cm, ideal for larger rooms. The high-end technology provides a transparent, uncolored sound, ideal for mixing and mastering applications.

Exceptional Audio Fidelity

The 5" Flax sandwich cone provides an ideal low-frequency response thanks to the high-quality flax fiber core sandwiched between two thin fiberglass layers. The result is high internal damping combined with exceptional speed of sound and bending stiffness. The technological methods used to create this Flax sandwich cone deliver ideal sonic neutrality, perfect for mixing and audio reference. At the heart of the Shape studio monitor are two Class AB amplifiers that power the drivers for outstanding audio performance. The result is controlled, articulated bass as well as detailed midrange response. The 1" M-shaped inverted aluminum/magnesium dome tweeter delivers exceptional high-frequency detail, combining with the Flax sandwich cone to produce a natural, rich sound.

DTM Surround

One of the most unique features included in the Focal Shape line is the TMD (Tuned Mass Damper). The damper surrounds the edge of the Flax sandwich cone woofer, stabilizing dynamic behavior at resonance, preventing cone deformation without affecting dynamics. This patented technology is used in earthquake-resistant skyscrapers and race car suspensions to provide additional resistance at the resonance frequency to control it. The result is minimized woofer cone fatigue over time, delivering a natural, rich midrange.

NIC - Neutral Inductance

Another exclusive technology incorporated into the Focal Shape design is NIC (Neutral Inductance Circuit Technology), which provides an incredibly stable magnetic circuit. The custom Faraday ring used for this was optimized using custom materials, dimensions and positioning to ensure that the magnetic field no longer affects the positioning of the voice coil. In turn, this guarantees the highest possible high-definition audio fidelity and performance. The result is high-definition audio that does not compromise detail or contrast.

Design and Construction

The Focal Shape Nearfield Studio Monitor is housed in an MDF enclosure with a natural walnut varnish, which not only looks elegant but also provides additional acoustic qualities. The rear of the unit features several settings for optimal integration, including a high-pass filter that can be bypassed, adjustable crossover (at 160Hz) and adjustable bass and treble. These attenuation controls allow it to adapt to any space or room to optimize audio quality and listening position. The enclosure also has threaded inserts for ceiling and wall mounting (mounting accessories not included).

Features

• Bi-amplified nearfield studio monitor

• Low tweeter directivity for flexible listening position

• Designed without a baffle allowing placement close to a wall

• Multiple settings for optimal integration

• Precise control, even at very high output

• Flax sandwich cone: controlled, articulated bass, natural and detailed mid and low registers.

• Threaded inserts for ceiling and wall mounts (mounting accessories not provided)

Specifications

System

• Frequency response (+/- 3dB): 50Hz - 35kHz

• Maximum SPL (music signal): 106dB SPL (peak @ 1m)

Electronics Section

• Inputs / Impedance Type: XLR: balanced 10kOhms

• Inputs / impedance connectors: RCA: 10kOhms unbalanced with sensitivity compensation

• Midrange & Low Frequency Amplifier: 60W, Class AB

• High Frequency Amplifier: 25W, Class AB

• Auto Standby:

  • Standby On: After approximately 30 minutes without signal

  • Standby Off: signal detection > 3 mV

• Power Supply:

  • Voltages: 220-240V (fuse T500mAL / 250V) or 100-120V (fuse T1.6AL / 250V)

  • Connection: IEC plug and detachable power cable

Settings

• High-pass filter: Full-range adjustable 45/60/90Hz

• Low: (0 - 250Hz) Adjustable, +/- 6dB

• Midrange / Bass: (160Hz, Q = 1) Adjustable, +/- 3dB

• High (4.5 - 35kHz): Adjustable, +/- 3dB

• On / Off: rear panel power switch

• Standby consumption: <0.5 W

• Display and controls: LED for on/off and standby

Transducers

• Woofer: 5" (13 cm) Flax cone

• Tweeter: 1" (25 mm) M-profile Aluminum-Magnesium

Enclosure

• Construction: 0.6" (12 mm) MDF

• Finish : Vinyl, real walnut and black paint

• Dimensions (with four rubber feet): 12.3 x 7.5 x 9.5" (312 x 191 x 242 mm)

• Weight: 20.7 lb (6.5 kg)

Solo6

2-way monitor

The versatile Solo6 2-way monitor offers unrivalled definition, transparency, dynamics and soundstage precision. Thanks to its Focus Mode, it forms two monitors in one, keeping you in the sweet spot when mixing, saving console space and simplifying cabling and monitor changes.

• Product type : 2-way monitor

• Loudspeakers :
  • Woofer : 6,5" W membrane
  • Tweeter : 1" Beryllium inverted dome

• Frequency response (+/- 3dB) :
  • 2-way mode: 40 Hz - 40 kHz
  • 1-way mode (Focus): 110 Hz - 10 kHz

• Maximum SPL (peak@1m) :
  110 dB

• Bass/midrange level (160 Hz) : Adjustable, +/-3 dB

• Inputs :
  XLR: symmetrical 10 kOhms

• High-pass filter :
  Full range, 45 Hz, 60 Hz, 90 Hz

• LED :
  • Power on
  • Focus mode
  • Clipping, default and stand-by

• Local supply :
  ~100-120 V, T2.5AL/250 V
  ~220-240 V, T1.25AL/250 V

• High frequency amplifier :
  50 W, class AB

• Bass level (>250Hz) : Adjustable, +/-3 dB

• Power on/of : On/Off switch on the rear panel

• Mid-range and low frequency amplifier :
  80 W, class G

• Treble level (< 4.5kHz) : Adjustable +/-3dB

• Indicators and controls :
  • Sensitivity
  • Auto standby
  • HPF, LF Shelv, LMF EQ, HF Shelv

• Height : 33.4 cm / 13.1 in

• Width : 24.6 cm / 9.7 in

• Depth : 29.5 cm / 11.6 in

• Weight : 13 kg / 28.6 livre

Active Nearfield Monitor

• Designed without a rear bass port - allows placing directly in front of a wall

• Power: 105 W Class AB

• Woofer: 6.5" Flax Cone

• Tweeter: 1" Aluminium-Magnesium

• 6.5" Double-passive membrane

• Frequency range (+/- 3 dB): 40 - 35000 Hz

• Max SPL peak @ 1 m (musical signal): 109 dB

• Input impedance: 10 kOhm

• Settings: High pass filter, bass, middle, high

• Power switch

• Automatic standby function

• Connections: XLR and RCA

• Thread connector for ceiling and wall brackets (mounting accessories not included)

• Dimensions (W x D x H): 218 x 285 x 355 mm

• Weight: 8.5 kg

• Housing: 12 mm MDF - Vinyl, walnut, black

Active Nearfield Monitor

• Tweeter with a low directivity for a flexible listening position

• Closed design with 2 passive diaphragms for easy positioning anywhere near a wall

• 2.5-Way design for optimal control of the basses and lower midrange

• Optimal integration via comprehensive settings

• Flax sandwich diaphragm for a controlled and defined bass reproduction and natural and detailed lower and upper mids

Technical specifications:

• Frequency response (+/- 3 dB): 40 Hz to 35 kHz

• Max. sound pressure level (music): 110.5 dB SPL (sound pressure level) (peak @ 1m)

• Electronics inputs/impedance type: XLR: balanced, 10 kOhm

• RCA connectors: unbalanced, 10 kOhm with compensation of the input sensitivity

• Power amp for the mid- and bass range: 2x 80W, Class AB

• Power amp for the treble range: 50 W, Class AB

• Automatic standby mode

• Shutdown after about 30 minutes without an input signal

• Exit standby mode: Via signal > 3 mV

• Power supply voltage: 220 to 240 V (fuse: T2AL/250 V) or 100 to 120 V (fuse: T3.15AL/250 V)

• Connections: IEC socket and separate power cable

• High-pass filter: Variable, range 45/60/90 Hz

• Bass level (0 - 250 Hz): Variable, +/- 6 dB

• Mid/Bass (160 Hz, Q = 1): Variable, +/- 3 dB

• Treble level (4.5 - 35 kHz): Variable, +/- 3 dB

• Power on/off: ON/OFF switch on the back

• Power consumption in standby mode: < 0.5 W

• LED for power on/off and standby

• Woofer: 2 x 5" (13 cm) flax cone woofer

• Tweeter: 1" (25 mm) aluminium/magnesium with M-profile

• Housing structure: 15 mm MDF

• Finish: Vinyl, walnut veneer, black lacquer

• Dimensions with 4 rubber feet (H x W x D): 478 x 211 x 279 mm

• Weight: 11 kg

Active Studio Monitor

• Tweeter: 1" inverted aluminium dome (35W Class D)

• Woofer: 8" Carbon fibre cone (80W Class D)

• Frequency range: 38Hz - 22kHz (+/- 3dB)

• Max. SPL: 106dB (peak @ 1m)

• Inputs: 1x jack (6.3mm, balanced), 1x XLR (balanced) and 1x RCA (unbalanced)

• Input impedance: 10kOhm

• Low shelf filter: +/- 6dB (0 - 250Hz)

• High shelf filter: +/- 3dB (4.5 - 35kHz)

• Auto standby after approx. 15 minutes without operation

• Dimensions (H x W x D): 390 x 296 x 330 mm

• Weight: 9.8 kg

• Includes cover grille

3- and 2-Way Monitor-in-One

• The monitor has the possibility to switch from 3 membranes to 2 membranes

• Enables comfortable comparison listening

• Rotatable baffle for mid-range and tweeter - equally suitable for horizontal or vertical orientation

• EQ Adjustment options for optimal room adjustment

• Optimized decoupling of the center driver via silent blocks

• Frequency response 3-way mode: 30 Hz to 40 kHz (+/- 3 dB)

• Frequency response 2-way mode: 90 Hz to 20 kHz (+/- 3 dB)

• Maximum SPL: 3-way mode: 118 dB (peak @ 1 m)

• Maximum SPL 2-way mode (focus): 105 dB (peak @ 1 m)

• Connections: XLR

• Sensitivity: +4 dBu or -10 dBV

• Amplifier: Bass: 300 W (Class G), Midrange: 150 W (Class G), Treble: 100 W (Class AB)

• Car standby

• Housing made of 21 and 30 mm MDF panels

• Internally strutted

• Dimensions: 635 x 345 x 450 mm

• Weight: 37.3 kg

• Unit price

Twin6 is at the service of reproduction, offering an uncompromising level of transparency and soundstage precision. Thanks to its innovative Focal technologies (Mode Focus, Beryllium inverted dome tweeter, "W" diaphragm), this studio monitor is a reliable and versatile tool that meets the needs of recording, mixing and mastering without the need for other monitors.

• Product type : 2.5-way monitor

• Loudspeakers :
  • Woofer : 2 x 6,5" W membrane
  • Tweeter : 1" Beryllium inverted dome

• Frequency response (+/- 3dB) :
  • 2-way mode: 40 Hz - 40 kHz
  • 1-way mode (Focus): 110 Hz - 10 kHz

• Maximum SPL (peak@1m) :
  112 dB

• Bass/midrange level (160 Hz) : Adjustable, +/-3 dB

• Inputs :
  XLR: symmetrical 10 kOhms

• High-pass filter :
  Full range, 45 Hz, 60 Hz, 90 Hz

• LED :
  • Power on
  • Focus mode
  • Clipping, default and stand-by

• Local supply :
  ~100-120 V, T2.5AL/250 V
  ~220-240 V, T1.25AL/250 V

• High frequency amplifier :
  50 W, class AB

• Bass level (>250Hz) : Adjustable, +/-3 dB

• Power on/of : On/Off switch on the rear panel

• Mid-range and low frequency amplifier :
  2 x 70 W, class G

• Treble level (< 4.5kHz) : Adjustable +/-3dB

• Indicators and controls :
  • Sensitivity
  • Auto standby
  • Midrange driver selector (right/left)
  • HPF, LF Shelv, LMF EQ, HF Shelv

• Height : 25 cm / 9.8 in

• Width : 50 cm / 19.7 in

• Depth : 34 cm / 13.4 in

• Weight : 22 kg / 48.5 lb

Trio6 is a professional monitoring loudspeaker offering flawless transparency, dynamics and sonic precision. Reliability and versatility are also its hallmarks, as evidenced by its dual Focus Mode, which enables Trio6 to form three monitors in one, for perfectly crafted, controlled mixes.

Focal Trio6 Black ST6; active 3-way bass reflex studio monitor; 8" woofer (W composite sandwich), 5" mid-woofer (TMD - Tuned Mass Damper) and 1.5" Beryllium tweeter with waveguide; selectable Focus mode: 1-way full-range monitor (mid-woofer only) or 2-way monitor (mid-woofer and tweeter); frequency range (-3dB): 35Hz - 40kHz in 3-way mode, 100Hz - 15kHz in Focus mode1, 80Hz - 40kHz in Focus mode 2; maximum SPL (50-10kHz, free field @ 1m): 115dB; amplifier power rating (RMS): x2 100W (woofer & mid-woofer) + 50W (tweeter); adjustable high-pass filter, low-shelving and high-shelving EQ and low-mid EQ (160Hz); switchable stand-by mode; adjustable input sensitivity (+4dBu / -10dBV); XLR input, Focus input and output (6.3mm jack); MDF enclosure with veneered side panels in black; dimensions (HxWxD): 537 x 292 x 367 mm; weight: 25kg

Sub One

Active professional subwoofer

This long-excursion active subwoofer offers high efficiency for the most demanding professionals and sound engineers. Rated at 200W RMS, Sub One is ideal for use with the Alpha Evo line, as well as the Shape line of monitors.

• Product type : Monitoring grave box

• Loudspeakers :
  2 x 8" Slatefiber membrane

• Frequency response (+/- 3dB) :
  32 Hz - 120 Hz

• Maximum SPL (peak@1m) :
  114 dB

• nputs :
  • Left,Right,LFE
  • XLR: symmetrical 10 kOhms
  • Variable

• LED :
  • Power on
  • Mute
  • Hi-pass defeat

• Local supply :
  100 - 240V - (T2AL fuse/250V)

• Power on/of : On/Off switch on the rear panel

• Mid-range and low frequency amplifier :
  100 W, class D

• Indicators and controls :
  • Sub level (sensitivity) adjustment
  • Lo-passe frequency adjustment
  • Phase adjustment
  • Polarity switch
  • Mute
  • 2.1 bypass (controlled by external footswitch)
  • Hi-pass frequency selection
  • Hi-pass defeat

• Height : 47.5 cm / 18.7 in

• Width : 31 cm / 12.2 in

• Depth : 52 cm / 20.5 in

• Weight : 18.5 kg / 40.8 livre
